Elation Design Spot 575E
Description
These Elation Design Spot 575E moving lights show signs of wear and tear but are in good working condition.
The Design Spot 575E by Elation Professional is an intelligent moving head spot and wash in one featuring full color mixing with CMY flag system plus a color wheel with 8 static dichroic color filters and 2 gobo wheels one with 6 rotating/indexing gobos and another with 6 static gobos with continuous, variable speed of each wheel scrolling in both directions. Additional features include variable frost, rotating 3facet prism, iris, zoom, focus, dimmer, shutter and animation effect wheel. The unit is available in black or white casing and is powered by Philips MSR 575/SA2DE discharge lamp providing up to 1,000 hours estimated lamp life. Rated at IP20 this unit is designed for indoor applications only and can operate from a user selectable 98 - 240v AC via the internal electronic power supply. Control data input is via 3 pin or 5 pin DMX data first in and out connections.
This item has been listed by a member of our worldwide community. Buying a brokered item like this is the perfect way to purchase hard to find equipment at a great price. All brokered item sales include a 72 hour (3 business days) quality inspection window. Once the item arrives, just let us know if you are unsatisfied- your purchase is guaranteed by UsedLighting.com!
Features
- 575W CMY moving head hybrid
- 8 Dichroic filters, 7 color, UV + White
- 2 gobo wheels, 12 total gobos, 6 metal, 6 glass
- 1 rotating animation wheel
- 3-facet rotating/indexing prism
- Both directions at variable speeds
- Macro-function for rotating gobos/rotating prism combinations
- Variable Frost Control
- Hard edge to soft edge
- Beam narrow to wide (5% - 100%)
- High output luminous-parabolic dichroic reflector
- Automatic Pan / Tilt position correction
- Maximum PAN-movement 630∞ in 2.0 secs (default) or 540 (user selectable) / 16 bit
- Maximum TILT-movement 265∞ in 1.5 secs / 16 bit
- Pre-set variable/random strobe and dimming pulse effect
- Vector Mode with blackout
- Motor driven focus from near to far
- All lenses are anti-reflection coated
- Sound active mode
- 29,700 lux @ 2.5M
- DMX control via 24 channels
- 32-Character LCD display
- On board menu settings
- Dimensions: (L x W x H) 18.70” x 14.37” x 24.41” / 474.98mm x 365mm x 620mm
- Weight: 63.8 lbs. / 29 kg
Additional Details
| Ships From: | San Diego, CA, USA |
| Manufacturer: | Elation Professional |
| Condition: | Good |
| Model: | Design Spot 575E |
| Item #: | 60595 (Brokered) |
| Tags: | Moving lights, Elation |
- (1) Design Spot 575E
- (2) Omega Bracket
A member from our team will reach out to the seller to determine the shipping cost and will contact you with the total cost for your approval. Payment will only be authorized, not processed, until the shipping cost is approved by you. Please note that if the item is being shipped to a country that is outside of the "Ships from" country, you will be responsible for any taxes, duties, or fees associated with your purchase.
Ships from: San Diego, CA, USA
